Cisco NCS 5502-SE (Network Convergence System 5502-SE) Fixed 48×100G Chassis
Cisco NCS 5502-SE Router – High-Performance 48×100G Fixed Chassis
Scalable, Secure, and Carrier-Grade Networking Solution for Service Providers & Enterprises
The Cisco NCS-5502-SE is a compact yet powerful 2RU modular router designed to deliver high performance, scalability, and reliability for service provider and enterprise networks. Equipped with advanced hardware and software capabilities, it supports Layer 2 and Layer 3 services, MPLS, Segment Routing, EVPN, and full IPv6.
Featuring 2 slots for line cards and a modular design, the NCS-5502-SE ensures investment protection while offering flexible port configurations, including 10GE, 25GE, 40GE, and 100GE options. With redundant power supplies, fans, and high-capacity forwarding performance, this router is ideal for modern networks demanding resiliency and scalability.
Whether you’re deploying for core, aggregation, or data center interconnect, the NCS-5502-SE combines Cisco’s industry-leading IOS XR software with hardware innovation to deliver carrier-class routing in a compact footprint.
Product Specifications for Cisco NCS-5502-SE
CLICK HERE FOR DATA SHEET
| Category | Details |
|---|---|
| Form Factor | 2RU modular router |
| Slots | 2 line card slots |
| Interfaces Supported | 10GE, 25GE, 40GE, 100GE (via line cards) |
| Fabric Capacity | Up to 2.88 Tbps |
| Forwarding Capacity | Up to 2.16 Tbps |
| Packet Forwarding Rate | Up to 1.44 Bpps (billion packets per second) |
| Software | Cisco IOS XR |
| Redundancy | Redundant power supplies and fans |
| Power Options | AC or DC (depending on PSU configuration) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -40°F to 158°F (-40°C to 70°C) |
| Dimensions (H × W × D) | 3.5 in × 17.5 in × 24 in (8.9 cm × 44.5 cm × 61 cm) |
| Weight | Approx. 52 lbs (23.6 kg) |
| Supported Protocols | MPLS, Segment Routing, EVPN, Layer 2/3 VPNs, IPv4/IPv6, QoS, NetFlow |
| Management | CLI, SNMP, NetConf/YANG, Cisco Network Services Orchestrator (NSO) |
| Compliance | NEBS, RoHS, WEEE |
FAQs for Cisco NCS-5502-SE
Q1: What is the primary use case of the Cisco NCS-5502-SE?
The router is built for service provider edge, aggregation, and data center interconnect, supporting both IP/MPLS and advanced routing services.
Q2: How many line cards can the NCS-5502-SE support?
It supports 2 line card slots, providing flexibility for different port speeds and densities.
Q3: Does the router support redundancy?
Yes, it has redundant power supplies and fans for high availability.
Q4: What software does it run?
It runs on Cisco’s carrier-grade IOS XR operating system, supporting advanced routing and automation.
Q5: What interface speeds are available?
Supported interfaces include 10GE, 25GE, 40GE, and 100GE (depending on the installed line cards).
